XSSMLXL

Specifications

Lifting Capacity750 lb
Standard Lift Height53"
Maximum Lift Height Upgrade171"
Lift Speed (FPM)10
Arrives AssembledYes
Drive System1" diameter ACME Screw
Battery Powered OptionYes
Constant Pressure Platform ControlYes
Emergency Stop Platform ControlLighted Emergency Stop with Alarm
Alarm ButtonLighted Emergency Stop with Alarm
Keyed Platform ControlOptional
Call-Send ControlsOne per Stop Included
Optional Call-Send ControlsKeyed and/or Wireless
Platform TypeSolid with Non-Skid Coating
Platform Size36" x 48" or 54" (34" Usable Width)
Optional Platform Sizes36" x 60" (34" Usable), 42"x 54" (34" Usable), 42" x 60" (40" Usable)
Platform ConfigurationStraight-Thru Access
Optional Platform ConfigurationsSame Side Entry-Exit, 90 Degree Adjacent Access
Upper Access RampNone Available
Lower Access Ramp36" Fixed or Auto-Folding Standard, Optional 42" Fixed or Auto-Folding
Grab RailIncluded
Guard Panel42"
Maximum Stops3
Other OptionsFire-Rated Doors, Automatic Door Openers

Specifications

Lifting Capacity750 lb
Standard Lift Height53"
Maximum Lift Height Upgrade171"
Lift Speed (FPM)10
Arrives AssembledYes
Drive System1" diameter ACME Screw
Battery Powered OptionYes
Constant Pressure Platform ControlYes
Emergency Stop Platform ControlLighted Emergency Stop with Alarm
Alarm ButtonLighted Emergency Stop with Alarm
Keyed Platform ControlOptional
Call-Send ControlsOne per Stop Included
Optional Call-Send ControlsKeyed and/or Wireless
Platform TypeSolid with Non-Skid Coating
Platform Size36" x 48" or 54" (34" Usable Width)
Optional Platform Sizes36" x 60" (34" Usable), 42"x 54" (34" Usable), 42" x 60" (40" Usable)
Platform ConfigurationStraight-Thru Access
Optional Platform ConfigurationsSame Side Entry-Exit, 90 Degree Adjacent Access
Upper Access RampNone Available
Lower Access Ramp36" Fixed or Auto-Folding Standard, Optional 42" Fixed or Auto-Folding
Grab RailIncluded
Guard Panel42"
Maximum Stops3
Other OptionsFire-Rated Doors, Automatic Door Openers
