Specifications

Lifting Capacity750 lb
Standard Lift Height53"
Maximum Lift Height Upgrade171"
Lift Speed (FPM)10
Arrives AssembledYes
Drive System1" diameter ACME Screw
Battery Powered OptionYes
Constant Pressure Platform ControlYes
Emergency Stop Platform ControlPit Switch Standard, Safety Underpan Option
Alarm ButtonLighted Emergency Stop with Alarm Option
Keyed Platform ControlOptional
Call-Send ControlsOne per Stop Included
Optional Call-Send ControlsKeyed and/or Wireless
Platform TypeSolid with Non-Skid Coating
Platform Size36" x 60" x 42" (34" Usable)
Optional Platform Sizes42"x 60" (40" Usable)
Platform ConfigurationStraight Thru Access
Optional Platform ConfigurationsSame Side Entry-Exit, 90 Degree Adjacent Access
Upper Access RampNone Available
Lower Access Ramp36" or 42" Fixed Ramp
Grab RailOptional
Guard Panel42"
Maximum Stops3
Other OptionsFire-Rated Doors, Automatic Door Openers

Specifications

Lifting Capacity750 lb
Standard Lift Height53"
Maximum Lift Height Upgrade171"
Lift Speed (FPM)10
Arrives AssembledYes
Drive System1" diameter ACME Screw
Battery Powered OptionYes
Constant Pressure Platform ControlYes
Emergency Stop Platform ControlPit Switch Standard, Safety Underpan Option
Alarm ButtonLighted Emergency Stop with Alarm Option
Keyed Platform ControlOptional
Call-Send ControlsOne per Stop Included
Optional Call-Send ControlsKeyed and/or Wireless
Platform TypeSolid with Non-Skid Coating
Platform Size36" x 60" x 42" (34" Usable)
Optional Platform Sizes42"x 60" (40" Usable)
Platform ConfigurationStraight Thru Access
Optional Platform ConfigurationsSame Side Entry-Exit, 90 Degree Adjacent Access
Upper Access RampNone Available
Lower Access Ramp36" or 42" Fixed Ramp
Grab RailOptional
Guard Panel42"
Maximum Stops3
Other OptionsFire-Rated Doors, Automatic Door Openers
